Histogram for megabase.fa


AminoSeeNoEvil

DNA/RNA Chromosome Viewer

A new way to view DNA that attributes a colour hue to each Amino acid codon triplet

Amino Acid Hue RGB Count Description
Non-coding NNN 120° 0 Expressed as NNN Codon
Ochre 0 STOP Codon
Glutamic acid 16° 0 Group III: Acidic amino acids
Aspartic acid 31° 0 Group III: Acidic amino acids
Amber 47° 0 STOP Codon
Cysteine 63° 0 Group II: Polar, uncharged amino acids
Glycine 78° 0 Group I: Nonpolar amino acids
Alanine 94° 0 Group I: Nonpolar amino acids
Methionine 110° 0 START Codon
Valine 125° 0 Group I: Nonpolar amino acids
Leucine 141° 0 Group I: Nonpolar amino acids
Isoleucine 157° 0 Group I: Nonpolar amino acids
Phenylalanine 172° 0 Group I: Nonpolar amino acids
Tryptophan 188° 0 Group I: Nonpolar amino acids
Serine 203° 0 Group II: Polar, uncharged amino acids
Threonine 219° 0 Group II: Polar, uncharged amino acids
Opal 240° 0 STOP Codon
Glutamine 250° 0 Group II: Polar, uncharged amino acids
Asparagine 266° 0 Group II: Polar, uncharged amino acids
Tyrosine 282° 0 Group II: Polar, uncharged amino acids
Arginine 297° 0 Group IV: Basic amino acids
Lysine 313° 0 Group IV: Basic amino acids
Histidine 329° 0 Group IV: Basic amino acids
TOTAL Start Codons 120° 0 Count of Methionine
TOTAL Stop Codons 120° 0 One of Opal, Ochre, or Amber
Proline 344° 0 Group I: Nonpolar amino acids
19 Amino Acids, 4 Start/Stop codes, 1 NNN . . . .

About Start and Stop Codons

The codon AUG is called the START codon as it the first codon in the transcribed mRNA that undergoes translation. AUG is the most common START codon and it codes for the amino acid methionine (Met) in eukaryotes and formyl methionine (fMet) in prokaryotes. During protein synthesis, the tRNA recognizes the START codon AUG with the help of some initiation factors and starts translation of mRNA. Some alternative START codons are found in both eukaryotes and prokaryotes. Alternate codons usually code for amino acids other than methionine, but when they act as START codons they code for Met due to the use of a separate initiator tRNA. Non-AUG START codons are rarely found in eukaryotic genomes. Apart from the usual Met codon, mammalian cells can also START translation with the amino acid leucine with the help of a leucyl-tRNA decoding the CUG codon. Mitochondrial genomes use AUA and AUU in humans and GUG and UUG in prokaryotes as alternate START codons. In prokaryotes, E. coli is found to use AUG 83%, GUG 14%, and UUG 3% as START codons. The lacA and lacI coding regions in the E coli lac operon don’t have AUG START codon and instead use UUG and GUG as initiation codons respectively.
